Casio TK-6500 - 5. TO OPEN THE UPPER CASE

- 7 -
5. TO OPEN THE UPPER CASE
1. Open the printer cover. Then, remove the
ribbon cover from the machine.
2. Remove the 2 screws of the upper case.
3. Push the 3 dots marking point at the right
side of lower case. At the same time, slide
the upper case to the front side.
4. Open upper case from the left side.
Remove the 2 screws.
Open the printer cover.
Slide the upper case
to the front side.
Remove the ribbon cover.
Power switch cover
Press the 3 dots marking point.
