Casio TK-6500 User Manual

N Item Code No. Parts Name Specification Q'ty Price code R
USA, Canada
SCREW 3X8PAI 8 ZMC-3 15 X
5. Power supply block
N
19 10013899 PCB/E445-S1 E340808A-1 1 AH X
N
F1 10017330 FUSE 2371.25 1 AB A
N
F2 10017328 FUSE 213002 1 AB A
IC1 21120829 IC LM2576HVT-5.0LB03 1 BO A
IC2 21120809 IC HA17431PA 1 AC A
N
D1 23153116 BRIDGE/DIODE D3SBA20 1 AH B
N
D2 23153117 DIODE D3S6M 1 AA B
D3 23153128 DIODE 1SR35-400AT-82 1 AA B
D4 23902828 DIODE RB441Q-40T-77 1 AA B
Q1 22303619 TRANSISTOR 2SD1193 1 AU B
N
T1 10017412 TRANSFORMER TE-475-E3U-1 1 DB B
ZD1 23153119 DIODE/ZENER RD39EB2 1 AA B
N
C1, 2 10021055 CAPACITOR R46K124705001M 2 AC C
C5 28203730 CAPACITOR ECQ-B1H-103-JZW 1 AA C
N
C6 10021059 CAPACITOR/ELECTROLYTIC LPH-50V103MS4 1 BT C
C7 28190743 CAPACITOR HE40TJYB101K 1 AA C
N
C8 10021060 CAPACITOR/ELECTROLYTIC RJH-50V101MH4 1 AE C
N
C9 10021061 CAPACITOR/ELECTROLYTIC RJH-16V331MG4 1 AE C
N
F1, 2 10017415 CLIP/FUSE UF0033 4 AA C
N
FT1 10017404 FILTER PLA10A3021R3R02B1 1 AJ C
L1 30008061 COIL MCDR1419-221K 1 AH C
N
SW1 30008067 SWITCH/AC SDDJE3-R 1 AT C
N
Q1 30008062 SINK/HEAT OSH-3050-SPL 1 AH X
JP1, JPB WIRE/J IPS-1009-2 3 X
R1 RESISTOR RD50SS102J 1 X
R2 RESISTOR SN14K2C123F 1 X
R3 RESISTOR SN14K2C132F 1 X
N
20 62481535 CABLE SUB ASSY/POWER E440715*1 1 AP C
21 37004281 CORD/POWER PS204 1 AV C
22 30304055 CORE/FERRITE L5T18X6X10 1 AC C
23 62481301 FIXTURE/POP-SW E440673-1 1 AB C
N
24 62481654 CASE/NF-U E140265-1 1 AQ C
N
25 62481279 CASE/NF-B E240517-2 1 AB C
BAND/MARK KN-1-N 1 X
SCREW 3X8 ZMC-3 2 X
SCREW 3X8 ZMC-3 2 X
SCREW 3X5 ZMC-3 2 X
SCREW 3X8 ZMC-3 1 X
TIE/INSULOCK T-18S 2 X
6. Connector board (COM2)
N
26 10007159 PCB/E445-CNB E340799A-1 1 AC X
30007917 PLUG/D-SUB ID9P33E4GX28 1 AK C
35405181 CONNECTOR HLW20R-2C7 1 AB C
30006937 PLUG TCP7361-11-0201 1 AH C
7. Upper case block
N
27 62481261 CASE/UPPER E140250-6 1 BQ C
N
28 62481720 PLATE/DISPLAY E140252-11 1 AV B
29 62481670 SWITCH SUB ASSY/MODE KEY E340762*2 1 AO B
CONNECTOR HLW9S-2C7 1 C
PCB/E475-E3-1 E340841-1 1 X
FRAME/MODE KEY SWITCH E240513-1 1 X
SCREW 3X8 ZMC-3..... 1 X
PLATE/SLIDE E411394-1 1 X
SHAFT/MODE KEY E311850A-1 1 X
SPRING/CONTACT E412058-2 1 X
30 62202505 BUSH/DISPLAY E310377-1 1 AC C
31 62481473 CABLE/FFC JOINT E440657-2 1 AC C
32 62481273 COVER/RIBBON E140260-3 1 AL C
N
33 62481289 COVER/JOURNAL E340749-1 1 AE C
N
34 62481676 COVER/PRINTER E140248-4 1 AW C
N
35 55001979 SPACER/LOCKING RSPLS-6L 2 AB C
N 55002010 CLIP CS-4U 1 AA X
51120124 SCREW 3X8 ZMC-3..... 7 AA X
51120132 SCREW 3X10 ZMC-3... 1 AA X
N 54400562 SCREW 3X20 ZMC-3... 2 AA X
8. Lower case block
N
36 10010824 CASE/LOWER E475B E140254B-3 1 CB C
37 62481536 BATTERY SUB ASSY E440746*1 1 BC C
38 62481537 CONNECTOR SUB ASSY E440747*1 1 AB C
39 30006692 BATTERY/LITHIUM VL3032/1F2 1 BB A
40 62213892 ROLLER/RP E233 E411377-1 2 AB B
41 62481489 CABLE SUB ASSY/DRAWER E440737*1 1 AC C
42 62481648 CABLE/FFC JOINT E440666-3 1 AE C
43 62481500 CABLE/FFC JOINT E440657-1 1 AG C
44 35900195 CONNECTOR SUB ASSY/1625-01R E31553-1(#20-300) 1 AD C
45 62481458 COVER/POW-SW E445 E340757-1 1 AE C
N
46 10010828 COVER/ROM E475 E340768A-1 1 AF C
N
47 62481646 GUIDE/ROM E475 E240524-1 1 AX C
N
48 10007124 PLATE/CONNECTOR FIXING E340736-2 1 AO C
N
49 10012386 PLATE/D-SUB FIXING E340774A-1 1 AE C
50 55001980 SPACER/LOCKING SPLSN-4 2 AA C
51 55300526 TERMINAL CE2 2 AA C
N
52 62481761 WIRE SUB ASSY/FG E440751*2 1 AA C
N
53 10010827 CHASSIS/B E445 E140261B-1 1 BQ X
54 62215004 GROMET B-1. 1 AA X
N
55 62481653 SCREW E440662-1 4 AA X
