Page #17 background image
17
To momentarily blank the image and mute the audio (BLANK)
1.
Press the [BLANK] key.
This blanks the screen by displaying the blank screen image specified by the Setup Menu
“Blank Screen” setting (page 28) and mutes the audio.
2.
To resume normal image and sound, press the [BLANK] key (or [ESC] key).
To freeze an image (FREEZE)
Press the [FREEZE] key to freeze the current input source image. To return to the real-time input
source image, press the [FREEZE] key again or press the [ESC] key.
To auto adjust an image (AUTO)
Press the [AUTO] key.
Pressing the [AUTO] key automatically adjusts the frequency and phase in accordance with the
input signal, which can reduce flickering and other projected image problems.
This operation is supported while the input source is Computer (RGB).
To change the aspect ratio of the projected image (ASPECT)
Press the [ASPECT] key to cycle through the aspect ratio settings for the projected image.
Available settings depend on your projector model as shown below.
XJ-V100W/XJ-V110W/XJ-F100W/XJ-F200WN/XJ-F210WN
Pressing the [ASPECT] key will cycle through settings in accordance with the current input source as
shown below.
* XJ-F100W/XJ-F200WN/XJ-F210WN only
XJ-V10X/XJ-F10X/XJ-F20XN
Pressing the [ASPECT] key will cycle through settings in accordance with the current input source as
shown below.
* XJ-F10X/XJ-F20XN only
Input Source Pressing the [ASPECT] key will cycle through these settings:
RGB, HDMI(PC) Normal Full 16:9 4:3 True
Video*, S-Video*, Component, HDMI(DTV) Normal 16:9 16:10 4:3 Letter Box
Input Source Pressing the [ASPECT] key will toggle between these settings:
RGB, HDMI(PC) Normal Full 16:9 16:10
Video*, S-Video*, Component, HDMI(DTV) Normal 16:9 16:10 4:3

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio XJ-V100W and is the answer not in the manual?

Casio XJ-V100W Specifications

General IconGeneral
Matrix size0.65 \
Native aspect ratio16:10
Projection distance- m
Projection technologyDLP
Contrast ratio (typical)20000:1
Screen size compatibility35 - 300 \
Projector native resolutionWXGA (1280x800)
Keystone correction, vertical-30 -30 °
Offset33 %
Throw ratio1.32 - 1.93:1
Zoom capabilityYes
Focal length range18.9 - 27.2 mm
Aperture range (F-F)2.31 - 2.73
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
Maximum analog resolution1920 x 1200 pixels
USB 2.0 ports quantity0
Password protection typePower on
Card reader integrated-
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.12 W
Power consumption (typical)135 W
Remote control typeIR
Harmonized System (HS) code85286200
Weight and Dimensions IconWeight and Dimensions
Width299 mm
Height97 mm
Weight3500 g
