Casio XJ-V100W User Manual

63
To project Mac OS computer screen contents over a USB
connection for the first time
1. Press the [INPUT] key. This will display the “Input” dialog box.
2. Use the [] and [] keys to select “USB Display” and then press the [ENTER]
key.
 This will cause the “USB Display” standby screen to be projected.
3. While your computer is running, use a commercially available USB cable to
connect the projector’s USB-B port to your computer’s USB port.
 The location of the USB-B port of this projector is indicated by “*2” in the illustration under
“Connecting Projector Cables” (page 11).
 This will cause a drive icon named “USB_DISPLAY” to appear on your computer screen.
4. Double-click the “USB_DISPLAY” drive icon to open it.
5. Double-click “MAC_USB_Display_V2.pkg” and follow the instructions that
appear on the display to install the application.
 A message prompting you to restart your computer will appear after installation is complete.
Restart your computer. After the restart is complete, you will see a CASIO USB Display icon in
the Dock.
6. In the Dock, click the CASIO USB Display icon.
 Also, CASIO USB Display will start up and display a licensing agreement dialog box.
7. On the licensing agreement dialog box, select “I agree” and then click [OK].
 This will display a window like the one shown below on your computer. At the same time,
projection of the computer’s screen contents will start.
 For information about the types of operations that can be performed at this point, see
“Supported Operations during Projection over a USB connection” (page 64).
Add-on Driver Software for Mac OS
With Mac OS, use of some parts of the CASIO USB Display requires installation of the driver software
shown in the table below. The driver software is the same as that used for Network Connection. You
can download it from the Network Connection download page at the CASIO website
(http://www.casio-intl.com/support/).
To use this function: Install this driver software:
Audio output function Sound flower
Extended desktop output function Syphon-virtual-screen

Casio XJ-V100W Specifications

General

Matrix size	0.65 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	20000:1
Screen size compatibility	35 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 -30 °
Offset	33 %
Throw ratio	1.32 - 1.93:1
Zoom capability	Yes
Focal length range	18.9 - 27.2 mm
Aperture range (F-F)	2.31 - 2.73
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Maximum analog resolution	1920 x 1200 pixels
USB 2.0 ports quantity	0
Password protection type	Power on
Card reader integrated	-
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.12 W
Power consumption (typical)	135 W
Remote control type	IR
Harmonized System (HS) code	85286200

Weight and Dimensions

Width	299 mm
Height	97 mm
Weight	3500 g
