Casio XJ-V100W User Manual

7
Useful Features and Functions
 Mercury-free Hybrid Light Source
A CASIO-original laser and LED hybrid light source enables high luminance, low power
consumption, and low running cost. This projector does not use a mercury lamp, making it
environmentally friendly.
 No-wait Projection
A CASIO hybrid light source reaches maximum brightness immediately after power is turned on,
compared with a wait of approximately one minute normally required with a mercury lamp. The light
source will even reach maximum brightness immediately if you turn it back on right after you turn it
off. A mercury lamp requires a longer wait in this case to cool down.
 Quick and simple light adjustment (Instant Light Control)
A simple key operation instantly adjusts light output to one of seven levels.
 Support for Three Input Sources
Analog RGB, component video (Y·Cb·Cr, Y·Pb·Pr), and HDMI input sources are supported.
 Vertical Keystone Correction
Manual adjustment to correct for vertical keystoning (distortion of the projected image shape
caused when projecting from below or above the projection surface) and return the projected image
to a rectangular shape.
 AUDIO OUT Terminal for Audio Output
Audio input via the projector’s HDMI terminal or AUDIO IN terminal is output from its AUDIO OUT
terminal. Amped speakers or other equipment can be connected to the AUDIO OUT terminal when
you want to output audio from another device via the projector.
 Ceiling Mounted and Rear Projection Support
The projector can be configured to project an image of normal orientation even when installed
upside down (for ceiling projection) or when projecting from behind the screen.
 Direct Power On
The projector can be configured to turn on automatically and start projecting as soon as it is
plugged into a power outlet.
 Firmware update
Firmware (software in the projector flash ROM) updates can be transferred to the projector from a
computer as required.
XJ-V10X/XJ-V100W/XJ-V110W

Casio XJ-V100W Specifications

General

Matrix size	0.65 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	20000:1
Screen size compatibility	35 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 -30 °
Offset	33 %
Throw ratio	1.32 - 1.93:1
Zoom capability	Yes
Focal length range	18.9 - 27.2 mm
Aperture range (F-F)	2.31 - 2.73
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Maximum analog resolution	1920 x 1200 pixels
USB 2.0 ports quantity	0
Password protection type	Power on
Card reader integrated	-
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.12 W
Power consumption (typical)	135 W
Remote control type	IR
Harmonized System (HS) code	85286200

Weight and Dimensions

Width	299 mm
Height	97 mm
Weight	3500 g
