Casio XJ-V100W User Manual

48
3. Perform fast forward, fast reverse, pause, and other operations as required.
 The operations described below are supported during movie file playback.
4. To return to the file menu, press the [ESC] key.
5. To return to the main screen, press the [FUNC] key and then the [ENTER] key.
To do this: Perform this operation:
Pause and resume movie playback Press the [ENTER] or [R] key.
 A pause icon ( ) is displayed in the upper left
corner of the projection screen while movie
projection is paused.
Re-play the file from the beginning 1. Press the [FUNC] key.
2. On the menu that appears, select “Play from
Beginning” and then press the [ENTER] key.
Toggle display of the movie playback time
between show and hide
Press the [FUNC] key. On the menu that appears,
select “Time Indicator On/Off” and then press the
[ENTER] key.
Fast forward at 2X, 8X, or 32X normal speed Press the [] or [d] key.
 The first press starts 2X speed fast forward, the
second press increases to 8X, and the third press
increases to 32X.
 The indicator appears in the upper left corner
during 2X fast forward, during 8X fast forward,
and during 32X fast forward.
Fast reverse at 2X, 8X, or 32X normal speed Press the [] or [s] key.
 The first press starts 2X speed fast reverse, the
second press increases to 8X, and the third press
increases to 32X.
 The indicator appears in the upper left corner
during 2X fast reverse, during 8X fast reverse,
and during 32X fast reverse.
Return from fast forward or fast reverse to
normal playback
Press the [ENTER] key or [R] key twice. Pressing
either of these keys only once will pause playback.
Press once more to start normal playback.
Jump to the final movie frame Press the [FUNC] key. On the menu that appears,
select “Go to End” and then press the [ENTER] key.
Stop movie file playback and return to the file
menu
Press the [ESC] key.
Total movie play time
Elapsed movie play time

Casio XJ-V100W Specifications

General

Matrix size	0.65 \
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	20000:1
Screen size compatibility	35 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 -30 °
Offset	33 %
Throw ratio	1.32 - 1.93:1
Zoom capability	Yes
Focal length range	18.9 - 27.2 mm
Aperture range (F-F)	2.31 - 2.73
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Maximum analog resolution	1920 x 1200 pixels
USB 2.0 ports quantity	0
Password protection type	Power on
Card reader integrated	-
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.12 W
Power consumption (typical)	135 W
Remote control type	IR
Harmonized System (HS) code	85286200

Weight and Dimensions

Width	299 mm
Height	97 mm
Weight	3500 g
