b. Differential Lock Switch
The Differential Lock function only can be activated when the vehicle is fully stopped and the
brake is applied. You must follow the below operation process to activate the differential lock
function:
1. Always stop the vehicle and apply the brake.
2. Apply the differential lock switch according to the terrain surface condition and your ridding
behavior.
3. Notice the ‘R” indication on the transmission gear position indicator of instrument panel
comes on. The engine speed will be limited when the differential lock switch is on but the
function is still not yet activated.
4. Turn the vehicle slowly in small radius till the differential lock indicator comes on. The engine
speed limit will be released.
5. Ride the vehicle carefully.
DIFFERENTIAL LOCK SWITCH (ESTOC ONLY)
1
2
Rear differential lock (FDS)
Normal
1
2
