cectek Kingcobra - Front Brake Lever; Throttle Cable Tension Adjuster; Throttle Limiter

61
e. Front Brake Lever
Apply the front brake
Pull the brake lever backward to apply the front brake.
f. Throttle Limiter
Release the lock nut and turn the throttle limiter screw to restrict the engine maximum power by
limiting the max throttle lever travel. Adjust the throttle limiter according to the rider’s skill and
experience adjust the throttle limiter.
To adjust the throttle limiter
1. Loose the locknut (1).
2. Turn the throttle limiter screw (2) clockwise to restrict maximum engine power or counter-
clockwise to increase the maximum engine power.
3. Tighten the lock nut (1).
THROTTLE LIMITER
1
2
Lock nut
Throttle limiter screw
1
d. Throttle Cable Tension Adjuster
Turn the nut to adjust the tension of throttle cable. The detail of adjustment is stated in the
Chapter: Maintenance Information.
1
1
2
