8.0 Order Guide
Sensor
Scales
CE300-40-PCB (example)
R5725-HC (example)
Eval PCB
PCB=mounted to evaluation PCB
1
Blank=unmounted chips
Interpolation
4=x4 (Model CE300 only)
40=x40 (Model CE300 only)
40GC=x40 (Model CE only)
Model
CE300
CE
Scale Mounting
For Linear Scales:
T=Tape
C1=3 clamps
2
C2=10 clamps
3
For Rotary Scales:
NH=No hub
HF=Standard hub (only valid for R1206CE and R1506CE)
HG= Standard hub (only valid for R1910CE)
HH= Standard hub (only valid for R3213CE)
HC= Standard hub (only valid for R5725CE)
HD= Standard hub (only valid for R10851CE)
Scale Model
Linear Scales:
L18CE=18 mm linear
L30CE=30 mm linear
L55CE=55 mm linear
L80CE=80 mm linear
L130CE=130 mm linear
L155CE=155 mm linear
L325CE=325 mm linear
Rotary Scales:
R1206CE=12 mm OD rotary
R1506CE=14.5 mm OD rotary
R1910CE=19.05 mm OD rotary
R3213CE=31.75 mm OD rotary
R5725CE=57.15 mm OD rotary
R10851CE=107.95 mm OD rotary
Notes:
1. Quantities of 1 – 9 only
2. 3 clamps for scales up to 130 mm
3. 10 Clamps for scales 155 mm or longer
