Introduction
IM-ChipEncoder-Series-Rev. 2 Page 3 ©2022 Celera Motion
ChipEncoder Series
Installation Manual and Reference Guide
1.4 Standards Compliance
ChipEncoders are RoHS and REACH compliant.
1.5 Related Documentation
ChipEncoders Series Data Sheet
ChipEncoders Series Interface Drawings
1.6 Manual Revisions
Version Date Notes
Rev. 2 04/21/2022
Changed stencil thickness. New values for Sin+. REACH
compliance.
1.7 Trademarks
ChipEncoder is a registered trademark of MicroE Systems®.
1.8 Special Conventions Used
The following symbols may be used in this document.
Symbol Description
Warning or caution: potential damage to parts.
Instructions show correct method.
Instructions show example of incorrect method.
See Section 2.2
Single click with the mouse on these highlighted
references to jump to specified places in instructions.
