3.0 System Overview
This section identifies parts for the installation. Use the information in this section to design the
mounting scheme for the encoder.
3.1 ChipEncoder Models
Example of ChipEncoder Installed on a PCB
CE300-4, CE300-40 (7 mm x 11 mm) Top View
CE-40GC (6 mm x 6 mm) Top View
Ceramic
Substrate
Riser
Castellations (x24)
Beam Splitter
Date Code and
Serial Number
Beam Splitter
Ceramic
Substrate
Riser
ChipEncoder
