Page 16 For technical questions, please call 1-888-866-5797. Item 62120
Tool Self-test
From System Setup, select Tool Self-test, then press OK.
Display Test
1. From Tool Self-test, select
Display Test, then press OK.
to start test. (Figure 3.9 )
Tool Self-test 1/3
Display Test
Keyboard Test
LED Test ?
Figure N
2. To verify that the LCD screen is
functioning properly, a color test will run.
3. Press ESC to exit the test.
Keyboard Test
1. From Tool Self-test, select
Keyboard Test, then press OK.
Keyboard Test
Press any key to
start test
key:
Double [ESC] to return
Figure O
2. Press each button to make sure they
are functioning properly. If functioning
properly, the correct name for each
button will display after the word “key:”.
3. Press ESC twice to exit the test.
LED Test
1. From Tool Self-test, select
LED Test, then press OK.
LED Test 1/3
RED LED ON
YELLOW LED ON
GREEN LED ON
Figure P
2. To verify that the LEDs are functioning
properly, select each LED then
press OK. If functioning properly,
the selected LED will light up.
3. Press ESC to exit the test.
