Page 34 For technical questions, please call 1-888-866-5797. Item 62120
Review Data - Mode $01 - Current Powertrain Diagnostic Data
View data from the last recorded test.
Note: Not all vehicles return the
same data, results may vary from
the examples given herein.
From the Main Menu, select
Review Data, then press OK.
Main Menu
1. Select and view data as needed.
Review Data 1/3
Live Data
I/M Readiness
Modules Present
Figure CA
Note: If necessary, have a qualified
technician Interpret the data.
Ready Test
CAUTION: Do not connect or disconnect
the Scan Tool while the ignition
is on or the engine is running.
1. Connect the Scan Tool according to
“Connect Scan Tool” on page 12.
2. Turn the vehicle’s ignition ON
with the engine OFF.
3. From the Main Menu, select
Ready Test, then press OK.
Main Menu
4. View test results.
Figure CB
Note: See “I/M Readiness Quick-
Check” on page 17 to interpret data.
To Next Page
