On-Board Monitor Test
Mode $06 Request On-Board Monitoring Test
Results for Specific Monitored Systems
View test data for Non Continuous Monitors.
This section contains advanced
functions. Some data may need to be
interpreted by a qualified technician.
Note: Not all vehicles return the
same data, results may vary from
the examples given herein.
1. From Diagnostic Menu, select
On-Board Mon. Test, then press OK.
Diagnostic Menu 7/11
?
Read Codes
02 Monitor Test
Erase Codes
Live Data
View Freeze Frame
I/M Readiness
On-Board Mon. Test
Figure BJ
2. Select vehicle manufacturer.
Vehicle Manufacturer 1/2
8
BUICK
BMW
CADILLAC ?
CHEVROLET
CHRYSLER
FORD
Figure BK
3. Select and view Monitors, their
tests and results as needed.
On-Board Mon. Test 1/10
A/F Sensor Bank Sensor 1
H02S Bank Sensor 2
Catalyst Mon. Bank 1 ?
EVAP
EGR Heater Mon.B1S2
Misfire
Misfire
Figure BL
Note: If necessary, have a qualified
technician Interpret the data.
