Page 26 For technical questions, please call 1-888-866-5797. Item 62120
Custom Data Set - Record Select PIDs
WARNING! DO NOT attempt to operate
the Scan Tool while driving the vehicle.
Have a passenger operate the Scan Tool.
1. Start the vehicle and begin driving.
2. From Record Data, have the
passenger select Custom Data Set,
then press OK.
………………..Record Data 2/3..
Complete Data Set
Custom Data Set
Unit of Measure ?
Figure AS
3. Custom Data Set screen shows
which buttons can be used to
select/deselect PIDs. Have the
passenger press any button to
move to the next screen.
……………Custom Data Set……… …..
[ ] – Select/Deselect
[ ] – Select/Deselect all
[OK] – Confirm
[ESC] – Cancel
Press any key to con.
Figure AT
4. Have the passenger
select/deselect PIDs.
……..Custom Data Set 4/20
FUELSYS1
FUELSYS2 ?
√
LOAD_PCT #001
ECT
SHRTFT1
LONGFTI
DTC_CNT
Figure AU
5. Have the passenger select
a Trigger Mode:
• Manual Trigger - Recording will begin
after memory location is selected.
• DTC Trigger - Recording will
begin when a DTC is detected.
…….……Pick Trigger Mode 1/2
Manual Trigger
DTC Trigger ?
Figure AV
6. From Select Memory, have
the passenger select a memory
location, then press OK.
…………….Select Memory 1/3..
Location #1 *
Location #2
Location #3 ?
Figure AW
Note: An asterisk (*) next to a
location indicates a recording already
exists there. Selecting this location
will overwrite it with new data.
