About Panoramic Power
®
and the Bridge
The Panoramic Power System monitors electrical energy consumption at the
site level as well as at the individual circuit level. It detects excess usage,
allowing organizations to identify and reduce energy, maintenance expenses
and monitor site level consumption.
The system consists of wireless, self-powered sensors engineered to allow for
rapid, non-invasive installation, with almost no disturbance to operations.
Sensors are easily attached to circuit breakers by snapping them onto the
outgoing electrical wire. They monitor the flow of electricity through the
magnetic field it creates and also use it as a power source. The sensors do not
require any maintenance.
Sensors report the power consumption to the bridge. The bridge in turn
transfers the circuit level information, along with readings originated by the
utility meter and read through a pulse input on the bridge, to PowerRadar, the
solution's cloud–based analytics platform. A single bridge can collect data from
up to 250 sensors and two utility meters, and multiple bridges can be used in a
single site to increase coverage.
Four generations of bridges were developed, with the fourth generation now
available:
Basic Entry Level Bridge (PAN-2-E-EWC-US/EU)
Advanced Cellular Bridge (PAN-2-H-3G-US/EU), featuring a SIM card slot.
Advanced 3
rd
Generation Bridge (PAN-2H-3G-US/EU V3), featuring a SIM card
slot and Modbus interface*.
Advanced 4
th
Generation Bridge (PAN-2H-3G-US/EU V4), featuring a SIM card
slot, Modbus interface* and two KY pulse inputs.
