Bridge Installation and configuration guide
Pulse Input Electrical Characteristics
Open terminal voltage: 5 V
Maximum current: 0.9 mA
Absolute maximum K-Y voltage input range: 0-26 VD
Minimum pulse width: 5 mS
Maximum pulse rate: 100 Hz
Maximum LOW state voltage: 1.2 V
Minimum LOW state current: 0.6 mA
Minimum HIGH state voltage: 2 V
Maximum HIGH state current (leakage): 0.4 mA
Configuring the Bridge
This section assumes you are familiar with networking procedures.
Accessing the Bridge Web Interface
This section describes how to access the bridge web interface for configuring
the relevant data communication mode.
Prerequisite
Use Internet Explorer 9.0 (and up), Google Chrome, or Firefox to access the
bridge web interface.
How to Proceed
3. On your PC, disable your Wi-Fi and disconnect the LAN cable.
4. Connect the bridge to the power source.
5. Once the bridge powers up, it performs a self-test, after which all
LEDs light up in sequence. For more information on LED status, see
Understanding the Bridge LEDs.
6. Make sure no USB device is connected to the USB port of the bridge.
7. Press the Configuration button for approximately 5 seconds, until
the LED lights solid red.
8. Connect the bridge to the PC using the LAN cable, only after the
LED lights solid red (indicating that the bridge is in configuration
mode).
