Instruction Manual CertoClav Vacuum Pro 45 l — Model STE-45-T
39
10.3.3 Example of a protocol printout
10.3.4 Print barcode
Navigate to the Logging tab and select the protocol last recorded on the left of the
screen. Press on the pressure symbol at the top right of the screen. Now select the
option “Print a tracing label”.
Header line 1
Header line 2
Header line 3
Protocol CertoClav Vacuum Pro Series
Model: VAC-PRO-45L
S/N.: 22ABCDEFGHJ
Program: 134°C HOLLOW
Program description:
3 x venting
134 °C 2.1bar 30min
Hollow instruments
wrapped or unwrapped
Media: NO
Cycle no: 971
Start time: 12.01.15 17:42:00
End time: 12.01.15 18:16:00
Result: PASSED
hh:mm:ss Temp °C Press [bar]
17:42:00 27.5 1.00
17:42:20 27.5 0.50
17:42:40 27.6 0.18
17:43:00 80.4 0.80
[…]
18:15:00 65.9 0.18
18:15:20 65.4 0.18
18:15:40 68.0 0.50
18:16:00 70.2 1.00
Program finished successfully
END
Signed by_____________________
Confirmed by _________________
Optional
