chapter 5000
page 67
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
AC2 LIFTING UNIT
(*) The acceleration time shown is the time from 0 Hz to 100 Hz (maximum selectable speed). This is the ideal
ramp calculated by the software; the real ramp could change according to the motor parameters setting and,
obviously, according to the load.
(**) The deceleration time shown in the table is the time from 100 Hz to 0 Hz. This is the ideal ramp calculated
by the software; the real ramp could change according to the motor parameters setting and, obviously,
according to the load.
(***) Adjustable with a 1Hz resolution in the 0 to 200 Hz range.
PROGRAMMED LEVEL
PARAMETER
UNIT 0 1 2 3 4 5 6 7 8 9
ACCELERATION DELAY (*) SEC 0.5 0.7 1.0 1.4 1.9 2.5 3.2 4.0 4.8 5.5
DELERATION DELAY (**) SEC 0.5 0.7 1.0 1.4 1.9 2.5 3.2 4.0 4.8 5.5
MAX SPEED UP HZ 65 80 95 110 125 140 155 170 185 200
MIN SPEED UP HZ 12.0 13.5 15.0 16.5 18.0 19.5 21.0 22.5 24.0 25.5
SPEED FINE (ALL) (***) HZ - - - - - - - - - -
MAXIMUM CURRENT % IMAX 47 53 58 64 70 76 82 88 94 100
AUXILIARY TIME SEC 0 0.2 0.4 0.8 1.0 1.5 2.0 3.0 4.0 5.0
PARAMETER SETTING TABLE
