1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
LIFTING PERFORMANCE
Here below the table with the performance of a STD machine.
Q1 = It corresponds to the maximum load of the machine at 3mt. (See capacity plate).
Q2 = It corresponds to the maximum load of the machine at maximum load.
FFL = Full free loft mast
TV = Total visibility mast
m/sec = Lifting speed: min 0.30 m/sec = it means 3.3 sec to cover 1 meter.
max 0.50 m/sec = it means 2 sec to cover 1 meter.
max 0.60 m/sec = it means 1.7 sec to cover 1 meter
Amp = Consuption of Ampere
P = Pressure
= Max pressure to max high
LIFTING
*
*
*
*
*
*
For fingertips / mini joysticks version the maximum pressure valve is set to 240 Bar
