chapter 5000
page 107
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
Press ROLL and PARAM together
Press ENTER
Press ROLL
with electric distributor
with mechanic distributor
Connect the console to the LIFTING logic unit
Press OUT
Press ENTER to confirm
LIFTING ACQUISITION (Lifting connection number 5)
* CONFIG. MENU *
SET MODEL
CONNECTED TO 5
JOYSTICK ON
JOYSTICK OFF
ARE YOU SURE?
YES=ENTER NO=OUT
AC2P2B D CE 1.06
48V 350A 00000
