CESAB C3E150 User Manual

chapter 5000
page 33
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
COLORI COLOURS FARBEN COULEURS COLORES
C arancio orange orange orange naranja
A azzurro blue blau bleu azul
B bianco white weiß blanc blanco
L blu dark blue dunkelblau bleu marine azul intenso
G giallo yellow gelb jaune amarillo
H grigio grey grau gris gris
M marrone brown braun marron castaño
N nero black schwarz noir negro
S rosa pink pink rose rosa
R rosso red rot rouge rojo
V verde green grün vert verde
Z viola/porpora purple violett violet púrpura
FINGERTIPS
RED : 5 V
GREEN : 0 ÷ 5(AT REST 2,5 V)
BLACK : 0 V
JOYSTICK
(FORWARD-BACKWARD MOV.)
ORANGE : 5 V
YELLOW : 0 ÷ 5 (AT REST 2,5 V)
RED : 0 V
JOYSTICK
(LEFT-RIGHT MOV.)
GREEN : 5 V
BLACK : 0 ÷ 5 (AT REST 2,5 V)
WHITE : 0 V
S1 - S3 - S5 - S7
S2 - S4 - S6 - S8
S1 - S5
S2 - S6
S3 - S7
S4 - S8
PB4 - PB5
