chapter 5000
page 42
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
PARAMETER CHANGE
MHYRIO UNIT
MIN EVP Min voltage on the draining solenoid valve
MAX EVP Max voltage on the draining solenoid valve
MIN EVP1 Min. voltage on the lowering solenoid valve
MAX EVP1 Max voltage on the lowering solenoid valve
MIN EVP2 Min. voltage on the lifting solenoid valve
MAX EVP2 Max voltage on the lifting solenoid valve
MIN EVP3 Min voltage on the backward tilt solenoid valve
MAX EVP3 Max voltage on the backward tilt solenoid valve
MIN EVP4 Min voltage on the forward tilt solenoid valve
MAX EVP4 Max voltage on the forward tilt solenoid valve
MIN EVP5 Min voltage on the sideshift right solenoid valve
MAX EVP5 Max voltage on the sideshift right solenoid valve
MIN EVP6 Min voltage on the sideshift left solenoid valve
MAX EVP6 Max voltage on the sideshift left solenoid valve
MIN EVP7 Min voltage on the 4th way forward solenoid valve
MAX EVP7 Max voltage on the 4th way backward solenoid valve
MIN EVP8 Min voltage on the 5th way forward solenoid valve
MAX EVP8 Max voltage on the 5th way backward solenoid valve
EVP OPEN DELAY Delay of the EVP in opening
EVP CLOSE DELAY Delay of the EVP in closing
EVP1 OPEN DELAY Delay of the EVP1 in opening
EVP1 CLOSE DELAY Delay of the EVP1 in closing
EVP2 OPEN DELAY Delay of the EVP2 in opening
EVP2 CLOSE DELAY Delay of the EVP2 in closing
EVP3 OPEN DELAY Delay of the EVP3 in opening
EVP3 CLOSE DELAY Delay of the EVP3 in closing
EVP4 OPEN DELAY Delay of the EVP4 in opening
EVP4 CLOSE DELAY Delay of the EVP4 in closing
EVP5 OPEN DELAY Delay of the EVP5 in opening
EVP5 CLOSE DELAY Delay of the EVP5 in closing
EVP6 OPEN DELAY Delay of the EVP6 in opening
EVP6 CLOSE DELAY Delay of the EVP6 in closing
EVP7 OPEN DELAY Delay of the EVP7 in opening
EVP7 CLOSE DELAY Delay of the EVP7 in closing
EVP8 OPEN DELAY Delay of the EVP8 in opening
EVP8 CLOSE DELAY Delay of the EVP8 in closing
