© Cesab 11 – 1 T Code(s): 841, 842, 843
Repair manual: Drive gear 2550 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
11. Drive gear 2550
11.1 General
The drive gear is a two-stage angle gear that is integrated with the motor and
brake assembly in a complete drive unit. The drive gear is fitted to the chassis
with bolts. At the top edge of the gear, the steering bearing and a gear ring
for the steering motor (option) are fitted.
These service instructions cover descriptions of service performed on site at
the customer. A complete reconditioning of the drive gear must be performed
in the workshop by trained technicians.
