CESAB S214L - 4.1 Battery is connected; 4.2 Login via keypad

© Cesab 4 – 3 T Code(s): 841, 842, 843
Repair manual: Operation and connection sequencesModel(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
4.1 Battery is connected
4.2 Login via keypad
Event Connection of battery
Preceding event
-
Action(s)
Connect the truck battery [G1]
Influencing
elements
Main power fuses OK [F1]
Operating circuit fuses OK [F50, F51]
Resulting
conditions
The status LED for the transistor regulator lights
continuously [T1].
Event Logging in
Preceding event
The battery is connected.
Action(s)
Enter a valid PIN code and press the ON button
on the keypad [S223].
Influencing elements
The emergency stop [S21] has not been activated
[T1:INP. SUPPLY+24V DC] {high}.
Tiller arm sensor in drive position [B60].
Resulting conditions
The power indicator lamp is lit. Main display
shows the hour counter for 4 seconds and after
this the battery charge level as a percentage of
full charge.
The mechanical brake remains applied [Q1]
[T1:OUT.BRAKE RELEASE] {high}.
