© Cesab 5 – 2 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
5.1.1 Show/change parameters
1: Make sure that the truck is switched off. Connect the CAN key or enter
the PIN code. Note: Do not press the ON switch.
2: Press and then release the horn button. “Info“ is shown on the display.
3: Move between menus by turning the speed control several times.
4: “Par” is shown on the display.
5: Press the horn button to select. The parameter symbol lights up.
6: By pressing the speed control repeatedly, you can move through the
parameter list.
See section “5. Parameters”.For setting parameters.
To show a parameter, release the speed control when the required parameter
is shown on the display. Press the horn button to change the parameter.
