CESAB S214L - Installing a logic card

© Cesab 13 – 12 T Code(s): 841, 842, 843
Repair manual: Tiller arm 4000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Installing a logic card
1: Fit the new logic card in place and connect it.
2: Check the cable connection on the logic card and that the connectors are
correctly connected.
3: Fit the cover in place and screw it down. Make sure the conduit entry is
intact and correctly positioned.
• Fit the upper cover. Page 13–9
Steps 1, 2
Step 3
Step 3
