CESAB S214L User Manual

© Cesab 20 – 2 T Code(s): 841, 842, 843
Repair manual: Electrical components and wiring diagrams Model(s): S210, S212, S212S, S212L, S214, S214L,
S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
P6 Display Truck function display
Q1 Electromechanical
brake
Mechanical brake
Q4 Solenoid valve Fork lowering
Q10 Contactor Main contactor
Q22
1
Solenoid valve Fork selector
Q23
2
Solenoid valve Support arm selector
S18 Switch Horn button
S21 Switch Emergency switch off
S97 Switch Warning lamp P5 Option
S206 Switch Turtle function Option
S111 Switch Option button Option
S113 Switch Option button Option
S114 Switch Option button Option
S115 Switch Option button Option
S116 Switch Option button Option
S223 Keypad/Smart card Login with PIN code
S224 Controls Sensilift Option
T1 Transistor regula-
tor
T7/T8 DC/DC converter T7=24V/12V
T8=24V/24V
Option
T20 Antenna Antenna Option
X1 Connector Battery
X21 Port DC/DC converter Option
X40 Port CAN communication (Extra I/O)
X41 Port CAN communication (External)
X65 Port Tiller arm:
1.Applies only to S212L, 214L and 220D.
2.Applies only to S212L, 214L and 220D.
