© Cesab 5 – 30 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Basic option 1 - Option switch controls SEU output
Argument #1
Selection of SEU unit 1 or 2
Values Meaning
0 option is handled by SEU unit 1 (A36)
1 option is handled by SEU unit 2 (the second SEU unit)
Argument #2
Selection of SEU digital output
Values Meaning Pin no.
0 activates digital output 1 (1.6 A) on SEU 16
1 activates digital output 2 (1.6 A) on SEU 30
2 activates digital output 3 (1.6 A) on SEU 2
3 activates digital output 4 (1.6 A) on SEU 3
Argument #3
Selection of option switch
Values Meaning
0 activated by option switch 2 or 5
1 activated by option switch 1
2 activated by option switch 2
3 activated by option switch 3
4 activated by option switch 4
5 activated by option switch 5
6 activated by option switch 6
7 activated by option switch 3 or 4
Argument #4
Type of switching
Values Meaning
0 activated when the switch is pressed
1 option is toggled when switch is pressed
