Cewe Prometer 100 - Storage of Logged Values

Page 44 of 72
Prometer 100 User Manual
BGX501-943-R01
Capacity in days
Number of logging channels
Logging
interval (min)
1
5
10
20
30
40
50
1
320
64
32
16
10
8
6
2
640
128
64
32
21
16
12
3
960
192
96
48
32
24
19
4
1000
256
128
64
42
32
25
5
1000
320
160
80
53
40
32
10
1000
640
320
160
106
80
64
15
1000
960
480
240
160
120
96
20
1000
1000
640
320
213
160
128
30
1000
1000
960
480
320
240
192
60
1000
1000
1000
960
640
480
384
Notes:
• Survey Integration Period (SIP) for Instantaneous parameters can be configured as 1, 2, 3, 4, 5, 10, 15,
20, 30 or 60 minutes.
• Survey Integration Period (SIP) for Energy parameters can be configured as 5, 10, 15, 20, 30 or 60
minutes.
• Maximum 1000 days can be configured
7.7.3 Storage of logged values
Logged values are saved with time stamps and flags that indicate events that have occurred during the logging
interval.
• The time stamp indicates the end-time. If the logging interval is configured to one hour, a value with the
time stamp 15:00 refers to the period 14:00 to 15:00.
• To indicate events or states during an interval, a logged value can be stored with one or more flags.
Event or state
Name of flag
Explanation
Time adjusted
T
During the past interval, the meter clock has been adjusted either instantaneous
or a sliding adjustment is in progress.
Time Disturbed D
The past interval is incomplete. For example, an interval shortened by the meter
being without auxiliary power or if the logging memory has been reset. The first
value after the logging memory having been configured will thus always be
indicated with "Faulty value” (the logging memory is reset in conjunction with
reconfiguration).
Alarm
A
In conjunction with user-defined alarms being configured, it may be specified that
an alarm will also be indicated with logged values. When a user-defined alarm has
triggered during the past interval, this is indicated with the flag “Alarm”.
Parameter
changed
P
The Prometer 100’s configuration, calibration or initiation has changed. Which of
these three the flag refers to can be seen in the event log.
Daylight savings
time
S Daylight saving time has been in effect during the past interval.
Voltage
loss/missing
V
During the past interval all measuring voltages have been lost or missing.
Field
Replaceable
Battery (for meter
reading/ RTC
backup)
B
Estimated battery lifetime is up.
Power loss
O
During the past interval, the meter has been without auxiliary power.
