Cewe Prometer 100 - Appendix G: List of DLMS Parameters

Page 68 of 72
Prometer 100 User Manual
BGX501-943-R01
Appendix G: List of DLMS Parameters
List of Profile Parameters (DLMS)
Section : Event Log 1 to 9 Snapshot Profile
Sr.No
Profile
Parameter
1 Instantaneous
Real Time Clock – Date and Time
2
Instantaneous
Cumulative Energy – Active Import
3
Instantaneous
Cumulative Energy – Active Export
4 Instantaneous Voltage – VRN for 3Ф4W / VRY for 3Ф3W
5
Instantaneous
Voltage – VYN for 3Ф4W
6
Instantaneous
Voltage – VBN for 3Ф4W / VBY for 3Ф3W
7
Instantaneous
Line Current – IR
8 Instantaneous Line Current – IY
9
Instantaneous
Line Current – IB
10
Instantaneous
Active Current – IR
11
Instantaneous
Active Current – IY
12 Instantaneous Active Current – IB
13
Instantaneous
Power Factor – R phase
14
Instantaneous
Power Factor – Y phase
15
Instantaneous
Power Factor – B phase
16 Instantaneous Voltage angle – Angle between R and Y phase
17
Instantaneous
Voltage angle – Angle between Y and B phase
18
Instantaneous
Voltage angle – Angle between B and R phase
List of Profile Parameters (DLMS)
Section : Event Log 10 Snapshot Profile
Sr.No Profile Parameter
1 Instantaneous
Real Time Clock – Date and Time
2
Instantaneous
Cumulative Energy – Active Import
3 Instantaneous Cumulative Energy – Active Export
4
Instantaneous
Voltage THD % - Phase 1
5
Instantaneous
3rd Harmonic Voltage - Phase 1
6
Instantaneous
5th Harmonic Voltage - Phase 1
7 Instantaneous 7th Harmonic Voltage - Phase 1
8
Instantaneous
9th Harmonic Voltage - Phase 1
9
Instantaneous
Voltage THD % - Phase 2
10
Instantaneous
3rd Harmonic Voltage - Phase 2
11 Instantaneous 5th Harmonic Voltage - Phase 2
12
Instantaneous
7th Harmonic Voltage - Phase 2
13
Instantaneous
9th Harmonic Voltage - Phase 2
14
Instantaneous
Voltage THD % - Phase 3
15 Instantaneous 3rd Harmonic Voltage - Phase 3
16
Instantaneous
5th Harmonic Voltage - Phase 3
17
Instantaneous
7th Harmonic Voltage - Phase 3
18
Instantaneous
9th Harmonic Voltage - Phase 3
