Prometer 100 User Manual
BGX501-943-R01
Appendix F: Connection and General Details
Electrical
Connection type
Common product for HV3/HV4/LV4 applications
Wiring configuration
3-phase 3-wire, 3-phase 4-wire
Voltage range (L-N/L-L)
57.7/100 V to 69.3/120 V (configurable) for HV3 & HV4
240/415 V for LV4 (applicable for Prometer 100-W only)
Current range
I
b
: 1-5 A (configurable)
I
max
: maximum 10 A (configurable)
Accuracy
Class 0.2s and 0.5s
Mains frequency
50/60 Hz ± 5%
Burden
If power drawn from Aux supply –
<0.1 VA /phase (for voltage and current circuit)
<10 VA (burden on Aux supply)
If power drawn from VT (i.e. self powered) –
<0.1 VA /phase (for voltage and current circuit)
<6 VA /phase (burden on VT supply)
STOC
10 times I
max
for 1 second
Compliance
Standards
IEC62052-11, IEC62053-22, IEC62053-23, IEC62056-52, IEC61010-1,
IEC61010-2-030, CE, MID (EN50470-1, EN50470-3)
Mechanical
Prometer 100-R
Dimensions (L X W X D)
428 x 133 x 260 mm approx. (meter with 19” rack)
299 x 133 x 260 mm approx. (meter with 11” rack)
Enclosure
Translucent polycarbonate cover (with clear transparent window for display)
and overall mild steel body
Sealing
Sealable screws on the front and back fascia of meter, sealing provision for
optical port and MD reset button
Weight
Meter – 3.8 kg approx. (± 1 kg)
11” rack – 2.1 kg (± 0.1 kg)
19” rack – 3.3 kg (± 0.1 kg)
Ingress Protection (IP) IP53 on front fascia and IP20 on back side
Prometer 100-W
Dimensions (L X W X D)
300 x 200 x 100 mm (± 5 mm)
Enclosure
Plastic material (type Polycarbonate)
Sealing
Sealable base and cover
Weight
2.5 kg approx. (± 0.5 kg)
Ingress Protection (IP) IP53 and IP54 with panel mounting kit over the front fascia
