Chamberlain LA400 - Control Box Parts; Gate Operator Arm Parts

1
2
3
4
44
ITEM PART # DESCRIPTION QTY
1 K001A6039 Control Board 1
2 K75-15480 Control Box & Cover
with Gasket 1
3 K75-30764 Control Board Bracket 1
4 K23-19380 Reset Switch 1
5 K74-19499 Antenna 1
6 K74-30762 Battery 2
7 K74-30763 Transformer 1
8 K76-19446 Alarm 1
Not Shown
K74-30941 ATC Fuse Kit Includes
20 Amp (1), 15 Amp (2)
K001A5747-2 Receiver Module - 390 MHz
K001A5747 Receiver Module - 315 MHz
K76-35600 Reset Switch (XLM Control Box)
K76-35364 Alarm (XLM Control Box)
GATE OPERATOR ARM
CONTROL BOX
ITEM PART # DESCRIPTION QTY
1 41ASWG-442SA Release Lever 1
2 41ASWG-438SA Motor with Limit 1
Switch Harness
3 41ASWG-0014SA Rear Connector 1
4 41ASWG-489 Cable 24 V with Connector 1
Not Shown
41ASWG-0119 Release Key 1
K77-19130 Hardware Bag
Complete with: Gate bracket, post
bracket, Pull-to-Open bracket and
hardware
REPAIR PARTS » CONTROL BOX + GATE OPERATOR ARM
8
2
7
4
6
5
3
1
Refer to the parts lists below for replacement parts available for your operator.
If optional modifications and/or accessories are included with your operator, certain
components may be added or removed from these lists.
1
2
3
4
5
6
7
8
1
2
3
4
