Chamberlain MIRACLE-ONE - PROCEDURE FOR INSTALLATION; Mounting Specifications (Open In;Out)

10.25"
90° / 105°
8.5"
6"
7.75"
25.75"
Miracle 1 in Closed Position
Miracle 1 in Open Position
Gate in Closed Position
Gate in Open Position
Out
In
PROCEDURE FOR INSTALLATION
Typical Masonry Column Setup
Typical Steel
Post Setup
Important:
Weld Re-Bar
Behind Gate
Hinges for
Maximum
Strength
Heavy Steel
Plates for
Reinforcement
(Not Supplied)
Heavy Steel Plates for
Reinforcement
(Not Supplied)
Gate Hinge
Gate Hinge
Steel Re-Bar
10"
Minimum
Back Steel Bracket
(Reinforce if necessary)
Back Steel Bracket
(Reinforce if
necessary)
Gate Hinge
Gate Hinge
Indexing on central hole in
the back steel bracket.
Indexing on
mounting hole in
the front steel
bracket.
6"
Top View
Post Setup
Heavy
Steel
Plate
Open To The Inside
9
