ALARM & MAGLOCK CONNECTIONS
123
2 Orange Wires
Connect for Open Inside
1. Ground - for Open Inside
2. Power
1234
UL Audio Alarm
Connection
Burglar Alarm
Relay Output
1. Common
2. N. O.
UL Audio Alarm Connection
3 and 4 UL Audio Alarm
1
2
2
1 or 3
3
4
Connect for Open Outside
2. Power
3. Ground - for Open Outside
Maglock Connection (Optional) Alarm Connection
Relay Contact Rating
0.5 A - 125 VAC
1 A - 24 VDC
Use the harness provided with the unit to make the connections to the alarm outputs. (Refer to next page)
OR
30
To Next Page
