Champion ci 40 - 6.0 TECHNICAL DATA

Champion Compressors Ltd. Manual No. 975203 Rev H
9
6.0 TECHNICAL DATA
UNIT
Ci 40 Ci 55 Ci 75 Ci 110
Pressure BAR 7 10 13 7 10 13 7 10 13 7 10 13
cfm 19 16 14 28 21 18 42 34 29 60 50 42
l/s 9.0 7.6 6.6 13.2 9.9 8.5 19.8 16.0 13.7 28.3 23.6 19.8
FAD
(Capacity)
m
3
/min 0.54 0.45 0.40 0.79 0.59 0.51 1.19 0.96 0.82 1.70 1.41 1.19
Drive
System
BELTS 2XPZ 2XPZ 2XPZ 2XPZ
Cooling Air
Vol.
L/Sec 250 250 1000 1000
Heat
Rejection
kW 5.1 7.0 9.5 13.4
Oil Fill Litres 3.5 3.5 4.0 4.0
Av. Sound
Pressure
Level
(10 Bar)
dB(A)
@ 1m
71 72 74 75
Air Outlet
Discharge
Size
DN
BSP ‘F’
DN20
3/4”
DN20
3/4”
DN25
1”
DN25
1”
Motor kW 4.0 5.5 7.5 11.0
RPM 50Hz
2890 2930 2930 2955
RPM 60Hz
3440 3480 3450 3545
IP 55 55 55 55
FLC / 380/50
A
8.5 / 9.4 11.8 / 12.9 15.7 / 17.3 (9.9) 22.8 / 14.3
o/load 415/50
A
8.1 / 8.9 11.1 / 12.2 14.7 / 16.2 (9.3) 21.2 / 13.4
Setting † 440/60
A
8.8 / 9.7 11.8 / 12.9 15.4 / 16.0 (9.7) 22.3 / 14.1
Australia:
Cable Size *
mm²
1.0 1.5 1.5 2.5
Fuse Size ♦
(MOTOR START)
A
25 32 35 35
Oils:
Factory Fill (Mineral)
SMARTLUBE CH46 SMARTLUBE CH46 SMARTLUBE CH46 SMARTLUBE CH46
High Ambient (Mineral)
SHELL CORENA S68 SHELL CORENA S68 SHELL CORENA S68 SHELL CORENA S68
Synthetic ♣
SULLUBE 32
SULLUBE 32 SULLUBE 32 SULLUBE 32
Motor Bearings SEALED BEARINGS - NO SERVICE REQUIRED
* Example as per AS3008.1.1 Selection of cables Table 12 (Column 4). Note that no
de-rating factors have been applied. Refer to AS3008.1.1 for correct selection and
installation.
♦ If circuit breakers are to be used, use only circuit breakers equivalent to MOTOR
START FUSE.
♣ Refer Champion Service if a change from mineral based oil to
synthetic is required.
† Overload settings in brackets are for Ci-75 with Star-delta starter.
