Champion Compressors Ltd. Manual No. 975203 Rev H
2
2.0 RECOMMENDED SPARE PARTS LIST
Description Repair Kit
No.
Qty.
2.1 Parts required per 1,500 hour (Type B)
Service
Standard Air Filter Element - Ci 40-55 278766 1
Standard Air Filter Element - Ci 75-110 278767 1
Oil Filter Element Cartridge - Ci 40-110 278877 1
Cyclonic Air Filter Element - Ci 40-110(Optional) 270092 1
Lubricant - Shell Corena CH46 (See Section 6) 831015
2.2 Parts required per 3,000 hour (Type C)
Service (As above plus:)
Separator Element - Ci 40-55 278773 1
Separator Element - Ci 75-110 278765 1
Microfilter Element - Ci 40-55 (If fitted) 211756 1
Microfilter Element - Ci 75-110 (If fitted) 211760 1
Vee Belts (Refer Section 9.0 / 10.0) 2
2.3 Machine Spares
Thermo Valve Repair Kit - 70ºC - Ci 40-110 278875 1
Thermo Valve Repair Kit - 80ºC - Ci 40-110 278876 1
Minimum Pressure Valve Repair Kit - Ci 40-110 278775 1
Inlet Controller - Ci 40-55 278905 1
Inlet Controller - Ci 75-110 278830 1
Airend Seal Kit - Ci 40-110 278763 1
Sight Glass Kit - Ci 40-110 278780 1
O-ring Kit - Ci 40-110 278874 1
Tensiometer 270965 1
2.4 Upgrade Kits
Cyclonic Air Filter Kit - Ci 40-55 159022
Cyclonic Air Filter Kit - Ci 75-110 159023
No Neutral, Hour Meter - Ci 40-55 159021
Clean Air Pack (CRD006) - Ci 40 159036
Clean Air Pack (CRD009) - Ci 55 159037
Clean Air Pack (CRD012) - Ci 75 159038
Clean Air Pack (CRD018) - Ci 110 159039
Acoustic Hood - Ci40-55 159017
Auto Drain Kit 159041
Spare parts Warranty: Type B Service items are warranted for 1000 hours. ULTIMIZER is warranted for 4000 hours (or 1 year,
whichever occurs first). CHAMPION Vee belts are warranted for 6000 hours, if installed by a Champion approved technician. The parts
subjected to warranty must be returned (freight pre-paid), with proof of purchase to Champion Compressors. In general, machine spare
parts are warranted for six months from the date of invoice and subject to Champion Compressors Ltd. standard Warranty Policy, and
Terms and Conditions of Sale of Goods.
