11.0 GENERAL ASSEMBLY COMPONENTS - Ci 40 / 55 - (9800660 Rev G)
Item Part No. Description Qty.
1 511132 Air Receiver - 380 Dia x 1200 Long 1
2 872267 Belt Guard - 500 x 250 x 85 1
3 872364 Bracket - Belt Guard - 245 x 150 x 15 1
4 741061 Pressure Switch - MDR3RM - Ci 40 - 7 & 10 bar 1
741062 Pressure Switch - MDR3RM - Ci 55 - 7 & 10 bar 1
741049 Pressure Switch - MDR3RM - Ci 40 - 13 bar 1
740150 Pressure Switch - MDR3RM - Ci 55 - 13 bar 1
5 521295 Platform W.A. - 745 X 320 X 120 1
6 491390 Cooler / Fan Assembly - Oil 1
6a 491399 Cooler - Part of Item 6 1
6b 481236 Fan - Part of Item 6 1
Motors - 380/415 50Hz, 440V 60Hz
7 351253 Motor - 5.5 kW - 2P - IP55 - TOP - Multivoltage - Ci 55 1
351276 Motor - 4.0 kW - 2P - IP55 - TOP - Multivoltage - Ci 40 1
8 301023 Integrated Screw - Ci 40 & 55 1
9 681718 Hose Assy - 3/8” - Cooler to Airend Oil Injection 1
9a N.S.S Elbow - 9/16” JIC x 1/2” BSPP - Part of Item 9 1
9b N.S.S Nipple - 9/16” JIC x 3/8” BSPP - Part of Item 9 1
10 681717 Hose Assy - 3/8” - Airend Oil Discharge to Cooler 1
10a N.S.S Elbow - 9/16” JIC x 1/2” BSPP - Part of Item 10 1
10b N.S.S Nipple - 9/16” JIC x 3/8” BSPT - Part of Item 10 1
11 681495 Hose Assy - 1/2” - Airend Air Discharge to Receiver 1
11a N.S.S Nipple - 3/4” JIC x 1/2” BSPT - Part of Item 11 2
12 601079 Taptite - M6 x 16 A.R
13 601037 Bolt - Hex Hd - M10 x 30 12
14 601091 Washer - M10 Mudguard 8
15 601086 Washer - M10 Spring 4
16 621010 Plug - Hex - Gal - ¼” BSP 2
17 371004 Clamp Plate - Motor - Ci 55 2
371005 Clamp Plate - Motor - Ci 40 2
18 721029 Over Temperature Switch - Oil Cooler - IP65 1
19 621066 Plug - Hex - Black - 1/2” BSPT 1
20 671004 Dowty Seal - 1/2” 1
21 601009 Washer - M10 Flat 8
22 781002 Gauge - Air Pressure - 63 Dia / 1600 kPa 1
23 541268 Valve - Safety - 1335 kPa - 1/4” BSP 1
24 601395 Grommet - 16mm 1
25 541025 Gate Valve - 3/4” 1
26 621469 Nipple - Gal - Hex Red - 1.1/2” BSPT x 3/4” BSPT 1
27 601053 Bolt - M12 x 75 - Tensioner Adjustment - Ci 55 3
601282 Bolt - M12 x 100 - Tensioner Adjustment - Ci 40 1
28 601007 Nut - ZP - M10 4
29 601017 Nut - Nyloc - M10 4
30 711079 Gland - PVC - M20 2
31 541173 Valve - Ball - 1/4"BSP M & F 1
32 711078 Reducer - PVC - 25 to 20mm 1
33 621571 Adaptor - Swivel - ¼” BSPF x 1/4” BSPM 1
33a 621609 Nipple - Hex - plt - ¼" BSPT - Seated 30 deg 1
To Next Page
