Champion Compressors Ltd. Manual No. 975203 Rev H
33
11.0 GENERAL ASSEMBLY COMPONENTS- Ci 40 / 55 (9800660 Rev G) - Continued
Item Part No. Description Qty.
Airend Pulleys
34 401312 Pulley - 2 SPZ x 106 - 1610 T/L - Ci 40 - 7 & 10 bar 1
401284 Pulley - 2 SPZ x 118 - 1610 T/L - Ci 40 - 13 bar 1
401304 Pulley - 2 SPZ x 95 - 1610 T/L - Ci 55 - 7,10 & 13 bar 1
35 411036 Taperlock Bush - Airend - 1610-25 - Ci 40 & 55 1
35a N.S.S Grub Screw - Part of Item 33 2
Motor Pulleys
36 401304 Pulley - 2 SPZ x 95 - 1610 T/L - Ci 40 - 7,10 & 13 bar 1
401312 Pulley - 2 SPZ x 106 - 1610 T/L - Ci 55 - 13 bar 1
401284 Pulley - 2 SPZ x 118 - 1610 T/L - Ci 55 - 7 & 10 bar 1
37 411172 Taperlock Bush - Motor - 1610-28 - Ci 40 1
411164 Taperlock Bush - Motor - 1610-38 - Ci 55 1
37a N.S.S Grub Screw - Part of Item 32 2
38 421101 Vee Belt - XPZ 937 - 7,10 & 13 bar 2
39 712331 Sleeving - Black - 10mm A.R.
40 631173 Bush - Reducing - ½"BSP M to 1/4"BSP F 1
