Champion Compressors Ltd. Manual No. 975203 Rev H
35
12.0 GENERAL ASSEMBLY COMPONENTS - Ci 75 - (9800657 Rev H)
Item Part No. Description Qty.
1 511135 Air Receiver 1
2 301020 Airend - Integrated Screw 1
Motors - 380/415 V 50 Hz, 440V 60Hz
3 351274 Motor - 7.5kW - 2P - TOP - IP55 - Multivoltage 1
4 491394 Cooler / Fan Assembly - Air / Oil - Emmegi 1
4a 491398 Cooler - Part of Item 4 1
4b 481235 Fan - Part of Item 4 1
5 521321 Platform W.A. 1
6 621609 Nipple - 1/4” BSPT - 30 deg Seated 1
7 601091 Washer - ZP - M10 Mudguard 4
8 681695 Hose Assembly - 1/2” - Oil Cooler to Airend Oil
Injection
1
8a N.S.S Elbow - 3/4” JIC x 1/2” BSPP 1
8b N.S.S Nipple - 3/4” JIC x 1/2” BSPP 1
9 681534 Hose Assembly - 3/4” - Airend Discharge 1
9a N.S.S Elbow - 1.1/16 JIC x 3/4” BSPT 1
9b N.S.S Elbow - 1.1/16 JIC x 1/2” BSPT 1
10 681654 Hose Assembly - 3/4” - Air Aftercooler to Receiver 1
10a N.S.S Nipple - 1” BSPT x 1” BSPT 1
10b N.S.S Elbow - 1.1/16” JIC x 3/4” BSPT 1
11 681696 Hose Assembly - 1/2” - Oil Discharge to Cooler Inlet 1
11a N.S.S Elbow - 3/4” JIC x 1/2” BSPP 1
11b N.S.S Nipple - 9/16” JIC x 1/2” BSPP 1
12 872539 Panel - Belt Guard Cover 1
15 601037 Bolt - Hex Hd - M10 x 30 8
16 872538 Panel - Belt Guard 1
17 872442 Angle - Door 2
18 872391 Panel - Rear 1
19 872313 Panel - Compressor Lid 1
20 872315 Panel - Door 1
21 872390 Panel - Front 1
22 601079 Taptite - M6 x 16 A.R
23 781009 Hour Meter - 48 Sq. - 240V 1
23a N.S.S Bracket - Hourmeter 1
24 9800673-4 Sound Foam - Front Panel - Cut Out 1
25 9800673-3 Sound Foam - Front Panel - Large 1
26 9800673-2 Sound Foam - Front Panel - Small 1
27 741063 Pressure Switch - MDR 3RM- 7 & 10 bar 1
741056 Pressure Switch-MDR 3RM - 13 bar 1
28a 861018 Seal Strip - 15 mm wide 2
28b 861018 Seal Strip - 15 mm wide 2
29 861035 Door Catch Kit - Black - 1000-V349 1
30 601086 Washer - ZP - Spring - M10 8
31 721029 Over Temperature Switch - Oil Cooler - IP65 1
To Next Page
