Champion Compressors Ltd. Manual No. 975203 Rev H
37
12.0 GENERAL ASSEMBLY COMPONENTS - Ci 75 - (9800657 Rev H) - Continued
Item Part No. Description Qty.
32 9800673-5 Sound Foam - Roof Panel - Rear 1
33 9800673-7 Sound Foam - Roof Panel - Front 1
34 9800673-1 Sound Foam - Rear Panel 1
35 541173 Valve - Ball - 1/4"BSP M & F 2
36 631173 Bush - Reducing - 1/2"BSP M to 1/4"BSP F 2
37 9800673-8 Sound Foam - Right End Panels 2
38 9800673-6 Sound Foam - Service Door 1
39 9800673-9 Sound Foam - Left End Panels 2
40 371004 Clamp Plate - Motor 2
44 601007 Nut - ZP - M10 4
45 861089 Handle - Pocket - Ci Series 2
46 601129 Nut - Nyloc - M10 4
47 601007 Washer - Flat - M10 8
48 621220 Nipple - Gal - 1” 1
49 541026 Gate Valve - 1” BSP 1
50 621067 Plug - Hex Blk - 3/4” BSPT 1
51 621064 Plug - Hex Blk - 1/8” BSPT 2
52 781002 Gauge - Air Pressure - 63 Dia/1600 kPa - Rear Entry 1
53 601053 Bolt - ZP - M12 x 75 2
54 601282 Bolt - ZP - M12 x 100 2
58 541268 Valve - Safety - 1/4” BSP - 1335 kPa - 6mm orifice 1
59 601395 Grommet - 16mm 1
60 621571 Adaptor - Swivel - 1/4” BSPF x 1/4” BSPM 1
61 711078 Reducer - PVC - 25/20 2
62 711079 Cable Gland - PVC - M20 2
63 601035 Bolt - Hex Hd - M10 x 20 4
Motor Pulleys
70 401313 Pulley - 2 SPZ x 160 PD - 2012 T/L 1
Airend Pulleys
71 401319 Pulley - 2 SPZ x 112 PD - 1610 T/L - 7 bar 1
401315 Pulley - 2 SPZ x 125 PD - 1610 T/L - 10 bar 1
401307 Pulley - 2 SPZ x 132 PD - 1610 T/L - 13 bar 1
72 421107 Vee Belt - XPZ1080 2
73 411002 Taperlock - Motor - 1210-38 1
73a N.S.S Grub Screw - Part of Item 63 2
74 411036 Taperlock - Airend - 1610-25 1
74a N.S.S Grub Screw - Part of Item 74 2
Star Delta Option (replaces items 19, 28, 32, 33 &
45)
75 872441 Panel - Compressor Top 1
