Champion Compressors Ltd. Manual No. 975203 Rev H
41
13.0 GENERAL ASSEMBLY COMPONENTS - Ci 110 - (9800745 Rev E)
Item Part No. Description Qty.
1 511135 Air Receiver 1
2 301020 Airend - Integrated Screw 1
Motors - 380/415/440 V 50 Hz, 440V 60Hz
3 351259 Motor - 11kW - 2P - TOP- IP55 - Multivoltage 1
4 491394 Cooler / Fan Assembly - Air / Oil - Emmegi 1
4a 491398 Cooler - Part of Item 4 1
4b 481235 Fan - Part of Item 4 1
5 521302 Platform W.A 1
6 872441 Panel - Compressor Top 1
7 872391 Panel - Rear 1
8 872390 Panel - Front 1
9 872538 Panel - Belt Guard 1
10 872539 Panel - Belt Guard Cover 1
11 872315 Panel - Door 1
12 872440 Panel - Electrical Door 1
13 872316 Angle - Door 2
14 861076 Hinge Set 2
15 861035 Door Catch Kit - Black - 1000-V349 1
16 9800747-5 Sound Foam - Roof Panel - Front 1
17 9800747-3 Sound Foam - Roof Panel - Top Large 1
18 9800747-9 Sound Foam - Roof Panel - Top Small 1
19 9800747-6 Sound Foam - Right End Panels 2
20 9800747-7 Sound Foam - Left End Panels 2
21 9800747-4 Sound Foam - Service Door 1
22 9800747-1 Sound Foam - Rear Panel 1
23 9800747-2 Sound Foam - Front Panel - Cut Out 1
23a 9800747-8 Sound Foam - Front Panel - Large 1
24 9800747-10 Sound Foam - Front Panel - Small 1
25 601091 Washer - ZP - M10 Mudguard 4
26 601053 Bolt - ZP - M12 x 75 2
27 601007 Nut - ZP - M10 4
28 601129 Nut - Nyloc - M10 4
29 601007 Washer - Flat - M10 8
30 891089 Handle - Pocket Compressor Cover 1
31a 861018 Seal Strip - 15 mm wide 2
31b 861018 Seal Strip - 15 mm wide 2
32 421107 Vee Belt - XPZ1080 - Ci 75/110 - All pressures 2
33 861099 Gas Strut - 200 N - 210 Stroke 1
34 621067 Plug - Hex Blk - 3/4” BSPT 1
35 371007 Clamp Plate - Motor - 254 mm 2
36 541268 Valve - Safety - 1/4” BSP - 1335 kPa - 6mm orifice 1
37 721029 Over Temperature Switch - Oil Cooler - IP65 1
38 541173 Valve - Ball - 1/4"BSP M & F 2
