Champion Compressors Ltd. Manual No. 975203 Rev H
43
13.0 GENERAL ASSEMBLY COMPONENTS - Ci 110 - (9800745 Rev E) - Continued
Item Part No. Description Qty.
38a 631173 Bush - Reducing - 1/2"BSP M to 1/4"BSP F 2
39 541026 Gate Valve - 1” BSP 1
40 621220 Nipple - Gal - 1” 1
41 621064 Plug - Hex Blk - 1/8” BSPT 2
42 681596 Hose Assembly - 1/2” - Oil Cooler to Airend Oil
Injection
1
42a N.S.S Elbow - 3/4” JIC x 1/2” BSPP 1
42b N.S.S Nipple - 3/4” JIC x 1/2” BSPP 1
43 681534 Hose Assembly - 3/4” - Airend Discharge 1
43a N.S.S Elbow - 1.1/16 JIC x 3/4” BSPT 1
43b N.S.S Elbow - 3/4” JIC x 1/2” BSPP 1
44 681533 Hose Assembly - 3/4” - Air Aftercooler to Receiver 1
44a N.S.S Nipple - 1” BSPT x 1” BSPT 1
44b N.S.S Elbow - 1.1/16” JIC x 3/4” BSPT 1
45 681535 Hose Assembly - 1/2” - Oil Discharge to Cooler Inlet 1
45a N.S.S Nipple - 9/16” JIC x 1/2” BSPT 1
45b N.S.S Nipple - 9/16” JIC x 1/2” BSPP 1
46 741005 Pressure Switch - XMP 1
741013 Pressure Switch - XMP - 13 bar 1
47 621609 Nipple - 1/4” BSPT 2
48 621011 Tee - Gal - 1/4” BSP 1
49 781002 Gauge - Air Pressure - 63 Dia/1600 kPa - Rear
Entry
1
50 621571 Adaptor - Swivel - 1/4” BSPF x 1/4” BSPM 1
51 601079 Taptite - M6 x 16 A.R
52 601037 Bolt - Hex Hd - M10 x 30 8
53 601035 Bolt - Hex Hd - M10 x 20 4
54 601086 Washer - ZP - Spring - M10 8
55 711263 Reducer - PVC - 32/25 2
56 711078 Reducer - PVC - 25/20 2
57 711079 Cable Gland - PVC - M20 2
Airend Pulleys
58 401318 Pulley - 2 SPZ x 90 PD - 1610 T/L - 7 bar 1
401314 Pulley - 2 SPZ x 100 PD - 1610 T/L - 10 bar 1
401312 Pulley - 2 SPZ x 106 PD - 1610 T/L - 13 bar 1
59 411036 Taperlock - Airend - 1610-25 1
59a N.S.S Grub Screw - Part of Item 59 2
Motor Pulleys
60 401305 Pulley - 2 SPZ x 180 PD - 2012 T/L 1
61 411032 Taperlock - Motor - 1210-42 1
61a N.S.S Grub Screw - Part of Item 61 2
To Next Page
