15.0 INTEGRATED SCREW COMPONENTS - Ci 75 / 110 - (9800879 - Rev A)
Item Part No. Description Qty.
1 301020 Airend - Integrated Screw 1
2 278780 Sight Glass - Oil 2
3 N.S.S. Cap Screw 4
4 621064 Plug - 1/8” BSP Black 2
5 N.S.S. Grub Screw - 3/8” BSP 1
6 541113 Oil Drain Tap - 3/8” BSP 1
7 278830 Inlet Controller Kit 1
8 278767 Element - Air Filter 1
9 278765 Element - Separator - Spin On 1
10 N.S.S. Cover - Air Filter 1
11 601163 Wing Nut - M6 1
12 278783 Safety Valve - Integrated Screw - 1500 kPa - Ci
Series
1
13 278770 Solenoid Valve - 240V - H Class Coil 1
14 278780 Sight Glass - Purge Line - Part of Sight Glass Kit 1
15 278775 Minimum Pressure Valve 1
16 N.S.S. Oil Filler Cap 1
17 N.S.S. Element - Thermovalve - 70º C 1
N.S.S. Element - Thermovalve - 80º C - Export 1
18 N.S.S. O-ring 1
19 N.S.S. Cover - Thermovalve 1
20 N.S.S. Slide - Thermovalve 1
21 N.S.S. Spring 1
22 278877 Element - Oil Filter Cartridge 1
23 N.S.S. Oil Filter Base 1
24 N.S.S. O-ring 1
25 N.S.S. O-ring 1
26 N.S.S. O-ring 1
27 N.S.S. Copper Washer 2
28 N.S.S. Copper Washer 1
29 N.S.S. Copper Washer 1
30 278859 Gasket - Inlet VV - Lower 1
31 278858 Gasket - Inlet VV - Upper 1
32 671155 O-ring - BS137 Viton 1
33 671156 O-ring - BS012 Viton 1
34 N.S.S. Plug 1
35 278879 Oil Return Orifice 1
Repair Kits
278875 Kit - Thermovalve 70º-Includes Items 17,18, 20 1
278876 Kit - Thermovalve 80º-Includes Items 17,18, 20 1
278763 Kit - Airend Seals Ci 40-110 1
278874 Kit - O-rings - Includes Items 18, 24, 25, 26 1
