Champion Compressors Ltd. Manual No. 975203 Rev H
53
17.0 CLEAN AIR PACK ASSEMBLIES - (9800668 Rev E)
Item Part No. Description Qty.
Clean Air Pack Components - Ci 40 & Ci 55
*1 182006 Refrigerated Dryer - Champion CRD006 1
182009 Refrigerated Dryer - Champion CRD009 1
2 521326 Mount W.A - Dryer 2
521329 Mount W.A - Dryer 2
3 681699 Hose Assy - ¾” - Receiver to Dryer 1
3a N.S.S Nipple - 3/8” BSPT x ½” BSPT - Part of Item 3 1
3b N.S.S Elbow - ½” BSP x ¾” JIC - Part of Item 3 1
4 211556 Micro Filter - Champion G5ZD 1
211756 G5ZD Filter Element 1
5 621561 Nipple - Hex Red - 3/8” BSPT x ½” BSPT -
CRD009
1
621700 Nipple - Hex - 3/8” BSPT - CRD006 1
6 621559 Elbow - ½” BSPF Swivel x ½” BSPT - CRD009 1
621819 Elbow -3/8” BSPF Swivel x 3/8” BSPT - CRD006 1
7 541025 Gate Valve - ¾” - CRD009 1
541024 Gate Valve - ½” - CRD006 1
8 621562 Nipple - Hex Red - ¾” BSPT x ½” BSPT - CRD009 1
621561 Nipple - Hex Red - ½” BSPT x 3/8” BSPT -
CRD006
1
9 601147 Taptite - Hex - Washer Face - M8x36 4
10 601037 Bolt - M10 x 30 4
11 601091 Washer - M10 Mudguard 4
12 601086 Washer - M10 Spring 4
Clean Air Pack Components - Ci 75 & Ci 110
*15 182012 Refrigerated Dryer - Champion CRD012 1
182018 Refrigerated Dryer - Champion CRD018 1
16 521327 Dryer Mount W.A - CRD012 2
521328 Dryer Mount W.A - CRD018 2
17 681700 Hose Assy - ¾” 2
18 621593 Elbow - 1/2” BSPT X 1.1/16”JIC 2
19 621592 Elbow - ¾” BSPT X 1.1/16”JIC 1
20 621593 Elbow - 1/2” BSPT X 1.1/16”JIC - CRD012 1
621592 Elbow - ¾” BSPT X 1.1/16”JIC - CRD018 1
21 621562 Nipple - Hex Red - ¾” BSPT x ½” BSPT - CRD012 1
621566 Nipple - Hex Red - 1” BSPT x ¾” BSPT - CRD018 1
22 872540 Bracket - Micro Filter 1
23 601440 Screw - Socket Head - M8x110 2
24 601004 Washer - M8 Flat 2
25 601157 Nut - Nyloc - M8 2
26 601002 Taptite - Cross Recess - Pan Hd - M6 2
27 601037 Bolt - M10 x 30 4
28 601091 Washer - M10 Mudguard 4
*: For Service and spares instruction - Refer to separate dryer manual supplied with compressor
