Champion Compressors Ltd. Manual No. 975203 Rev H
57
18.0 CYCLOPAC AIR INTAKE ASSEMBLIES - (9800688 Rev D)
Item Part No. Description Qty.
Ci 40 - 55
1 561354 Clamp - Hose - Worm Drive - 40 to 60 mm 4
2 561096 Rubber - 90 Deg Elbow 1
3 681570 Tube - Aluminised - 2” - 300 X 270 1
4 681582 Hose - Rubber - 2” id x 105 Long 1
5 561051 Mounting Band - Cyclopac - 5.21 id 2
6 561049 Filter - Air - Cyclopac - FWA05-2526 1
6a N.S.S. Air Filter Body - 5” 1
6b 270092 Element - Air Filter - 5” 1
6c N.S.S. Filter Body Clamp 1
6d N.S.S. Standard Cup Assembly 1
7 601004 Washer - Flat - Zinc PL 4
8 601086 Washer - Spring - Zinc PL 4
9 601003 Nut - Hex - Zinc PL - M8 4
10 601006 Bolt - Hex Hd - Zinc PL - M8 x 20 4
11 631025 Tube Fitting - Str Conn - ¼” x 1/8” BSPM 1
12 681002 Tube - ¼” Nylon A.R.
13 631024 Tube Fitting - Elbow - ¼” x 1/8” BSPM 1
Ci 75 - 110
14 861077 Seal Strip - P. Mould - Nitrile 1
15 N.S.S. Air Filter Cover 1
16 561200 Clamp - Hose - Worm Drive - 35 to 53 mm 1
17 561354 Clamp - Hose - Worm Drive - 40 to 60 mm 3
18 561454 Reducer - Rubber - 2” to 1 ½” 1
19 681583 Tube - Aluminised - 2” - 80 x 80 1
20 681582 Hose - Rubber - 2” id x 80 Long 1
21 561049 Filter - Air - Cyclopac - FWA05-2526 1
21a N.S.S. Air Filter Inlet Hood 1
21b N.S.S. Air Filter Body - 5” 1
21c 270092 Element - Air Filter - 5” 1
21d N.S.S. Filter Body Clamp 1
21e N.S.S. Standard Cup Assembly 1
22 561051 Mounting Band - Cyclopac - 5.21 id 2
23 601006 Bolt - Hex Hd - Zinc PL - M8 x 20 4
24 601004 Washer - Flat - Zinc PL 4
25 601086 Washer - Spring - Zinc PL 4
26 601003 Nut - Hex - Zinc PL - M8 4
To Next Page
