Champion Compressors Ltd. Manual No. 975203 Rev H
65
22.0 CENTRAL CONTROL BOX ASSEMBLY (Duplex option only)- (9800719 Rev B)
Item Part No. Description Qty.
1 712028 Contactor - CL25 2
2 712045 Overload - RT1P 2
3 781117 Hour Meter - 240V - Din Rail Mount 2
4 711075 Fuse Holder 4
5 711221 Fuse Link - 2 Amp 3
6 711222 Fuse Link - 4 Amp 1
7 711980 Transformer - 415 / 24 - 240VAC 1
8 711063 Relay Base - 2 Pole 10
9 711829 Relay Base - 4 Pole 2
10 711062 Relay - 240V - 2 Pole 6
11 711981 Relay - 24V - 2 Pole 4
12 711574 Relay - 240V - 4 Pole 2
13 711048 Terminal Block 51
14 711349 Terminal Block - Earth 4
15 711046 Terminal Block - End Cover 4
16 741004 Pressure Switch 2
17 591007 Pressure Switch Fitting 2
18 631051 Fitting - Tube - Elbow - 1/4”T x 1/4”BSPM 1
19 681002 Tube - Nylon - 1/4” A.R.
20 631026 Fitting - Tube - Tee - 1/4”T x 1/4”BSPM 1
21 601138 Locknut - Brass - 3/8” 2
22 712150 Enclosure - Electrical 1
23 711140 Duct Grey - PVC - 25 x 60 A.R.
23a N.S.S. Duct Cover - Grey PVC A.R.
24 711137 Din Rail - Omega A.R
25 N.S.S. Panel - Switchgear 1
