Champion ci 40 - 27.0 GENERAL ARRANGEMENT DRAWINGS; Fig. 8 - Ci 40; 55 Standard

Champion Compressors Ltd. Manual No. 975203 Rev H
67
23.0 LEAD / LAG CONTROL BOX DOOR ASSEMBLY - (9800862 Rev A)
Item Part No. Description Qty.
1 712144 Holder - Switch or Lamp - Labelled 8
2 712004 Push Button - Emergency Stop 1
3 712067 Selector Switch - 2 Position 1
4 712127 Selector Switch - Illuminated - Green - 2 Position 2
5 712335 Push Button - Flush - Reset 1
6 712145 Lens Cap - Green 1
7 712147 Lens Cap - Red 2
8 712158 Globe - 240V 5
9 712157 Base - Globe 5
10 712079 Contact Block - N/C & N/O 2
11 712002 Contact Block - N/O 2
12 712003 Contact Block - N/C 3
13 712114 Contact Block - N/O & N/O 1
14 712334 Electrical Enclosure - 300 x 400 x 210 1
