Champion ci 40 - Fig. 10 - Ci 75 SD; 110 Standard

Champion Compressors Ltd. Manual No. 975203 Rev H
69
24.0 LEAD / LAG CONTROL BOX ASSEMBLY - (9800889 Rev A)
Item Part No. Description Qty.
1 712028 Contactor - CL25 2
2 712045 Overload - RT1P 2
712043 Overload - RT1N 2
712046 Overload - RT1S 2
3 711075 Fuse Holder 3
4 711221 Fuse Link - 2 Amp 2
5 711222 Fuse Link - 4 Amp 1
6 712184 Transformer - 415/240V - 60VA 1
7 712063 Relay Base - 2 Pole 4
8 711062 Relay - 2 Pole 4
9 711048 Terminal Block - 4mm sq. 4
10 711349 Terminal Block - Earth - 4mm sq. 3
11 711047 Terminal End Cover 1
12 741004 Pressure Switch 2
13 591007 Pressure Switch Fitting 2
14 631051 Fitting - Tube - Elbow - ¼”T x ¼”BSPM 1
15 631026 Fitting - Tube - Tee - ¼”T x ¼”BSPM 1
16 601138 Locknut - Brass - 3/8” 2
17 712334 Enclosure - Electrical 1
