25.0 DUPLEX ASSEMBLIES - (9800723 Rev D)
Item Part No. Description Qty.
1 511138 Air Receiver - 440 x 1800 1
2 159019 Central Control Box - Lead / Lag, Remote Monitoring /
Control
1
711897 Lead/Lag Control Box (Lead / Lag Only Option) 1
3 872347LH Panel - Mounting Bracket - Left Hand 1
4 872347RH Panel - Mounting Bracket - Right Hand 1
5 681567 Hose - 3/4” - To Be Cut To Size 4m
5a N.S.S. Hose - Discharge to Wet Air Receiver 2
5b N.S.S. Hose - Wet Air Receiver to Filter 1
5c N.S.S. Hose - Filter to Dryer Inlet 1
5d N.S.S. Hose - Dryer Outlet to Filter 1
5e N.S.S. Hose - Filter to Dry Air Receiver 1
8 631051 Fitting - Tube - Elbow - 1/4”T x 1/4”BSPM 1
9 681002 Tube - Nylon - 1/4” A.R.
10 541268 Valve - Safety - 1/4" BSP - 1335 kPa (Not Shown) 2
To Next Page
